Rear Brake Caliper Rebuild Kit for Polaris Sportsman 400 500 Scrambler 400 500 Magnum 425 Xplorer Xpress 1994-2002 Replaces 1910180

$74.62

~~$100.10~~ $74.62

Sale Sold out

Shipping calculated at checkout.

Default Title Default Title

Restore your classic Polaris to factory braking standards for a fraction of the price of a new caliper.

Brand Name: M MATI

Origin: Mainland China

Item Height: 2.95

Item Weight: 0.7 KG

Material Type: iron

For ATV Brand/Model: Polaris

Item Length: 4.72

Item Width: 3.54

Model Name: PL0127

MPN：1910224 1910180 5131272 5130946 5131117

Repalcement MPN：1910156 1910209 1910226

Package: Rear Brake Caliper Rebuild Kit x 1

Warranty：1 Year

Fit for Polaris ATV/UTV as Following

300 1994-1995

400 1994-1995

Magnum 425 2x4/4x4 1995-1998 Exclude 6x6 Edition

Scrambler 400 1995-1997

Scrambler 500 1997

Sport 400 1994-1998

Sportsman 400 1993-1997

Trail Blazer 250 1994-1998

Trail Boss 250 1994-1999

Xplorer 300 1996-1999

Xplorer 400 1995-1998

Xpress 300 1996-1999

Xpress 400 1996-1997

Clean the Bore: Use a plastic scrub pad and brake cleaner to thoroughly clean the inside of the caliper bore. Any leftover corrosion or "pitting" will tear the new seals and cause an immediate leak.
Piston Inspection: Before installing the new seals, inspect the brake piston for scratches or nicks. If the piston surface is rough, it must be polished with fine steel wool or replaced, otherwise, the new seals won't hold pressure.
Lube the Seals: Apply a small amount of fresh DOT 3 or DOT 4 brake fluid to the new O-rings before sliding them into the caliper grooves. Never install seals "dry," as they can pinch or tear during assembly.
Grease the Slide Pins: The "floating" nature of this caliper depends on the slide pins. Clean the pins and apply a thin layer of high-temp silicone brake grease. If the pins are stuck, your brakes will wear unevenly and drag.
Bleeding Air: Rear brakes on older Polaris models can be difficult to bleed because the lines are long. Use a vacuum bleeder if possible, and ensure the bleeder screw is at the highest point of the caliper during the process.

🔍 Troubleshooting Guide

Issue	Possible Cause	Solution
Brake Fluid Leaking	Pinched seal or pitted caliper bore.	Remove the piston and inspect the seals. If the seals are fine but it still leaks, the caliper body itself is likely too corroded to seal.
Brakes Dragging/Overheating	Seized slide pins or stuck piston.	Ensure the caliper moves freely on its mounting pins. If the piston won't retract, check if the master cylinder return port is clogged.
Spongy Brake Pedal	Air trapped in the caliper.	Re-bleed the system. On these models, air often gets trapped in the top of the caliper. Try unmounting the caliper and holding it so the bleeder is the highest point.
No Brake Pressure	Failing rear master cylinder.	If the caliper is rebuilt but the pedal still goes to the floor, the seals in your foot-brake master cylinder have likely failed.
Squealing After Rebuild	Contaminated pads or un-greased pins.	Ensure no brake fluid or grease got onto the brake pads. Verify that the pad-retaining clips are seated correctly.
